MultiChill Modular Chiller with Free Cooling & Heat Pump
53kW-103kW
MultiChill™ is Airedale’s range of smaller capacity chillers and heat pumps, designed for modular installation. It is part of our more sustainable range of cooling and heating solutions, offering an energy efficient free cooling option and a lower GWP refrigerant.
Available as cooling only or as a heat pump variant
Modular configuration, delivering up to 1360kW of installed capacity
Excellent part-load efficiency benefits
Optimised for lower GWP refrigerant R32 (GWP 675)
Free cooling operation available
SEER up to 4.89 (cooling only) and SCOP of up to 4.08 (heat pump).
MultiChill™ is Airedale’s range of smaller capacity chillers and heat pumps, designed for modular installation. It is part of our more sustainable range of cooling and heating solutions, offering an energy efficient free cooling option and lower GWP refrigerant R32 (GWP 675).
MultiChill is available as a modular system, enabling simple interconnection of up to 16 units in a 4 x 4 arrangement delivering up to 1360kW of installed capacity. The controller can manage 16 MultiChill units to deliver increased system efficiency, part load operation and redundancy.
Optimised for minimum clearance air flow, with a frame design specially developed for modularity and an including an integrated system tank, the MultiChill range provides a sensible, sustainable option.
| Chiller | Number of circuits | Max Cooling Capacity (kW) | Max Heating Capacity (kW) | Max EER | Max SEER | Min Dimensions (mm) (H x W x L) | Max Dimensions (mm) (H x W x L) |
| MultiChill Cooling Only* | 1 | 85.1 | N/A | 3.21 | 4.89 | 2152 x 1130 x 2364 | 2152 x 1130 x 3220 |
| MultiChill Heat Pump** | 1 | 85.3 | 91.2 | 3.15 | 4.64 | 2152 x 1130 x 2364 | 2152 x 1130 x 3220 |
| MultiChill Free Cool*** | 1 | 103.0 | N/A | 4.14 | 4.56 | 2152 x 1130 x 2364 | 2152 x 1130 x 3220 |
*Based on chilled water at 7/12°C in a 35°C ambient
**Based on chilled water at 7/12°C in a 35°C ambient and hot water at 40/45°C ambient 7°C
***Based on chilled water at 18/23°C in a 35°C
